POWER SUPPLY |
|
|
- INPUT:110V,120V AC OR 220V,230V AC 50Hz OR 60Hz
|
| Model |
Output?? |
Source Regulation |
Load Regulation |
Ripple(rms) |
Size(mm) |
Weight(kg) |
Voltage |
Current |
| PS1502 |
0-15V |
2A |
<0.01%
+0.5mV |
<0.3%
+0.5mV |
??1mV |
220x190x200 |
2.8 |
| PS1503 |
3A |
3 |
| PS1505 |
5A |
240x190x200 |
3.8 |
| PS1510 |
10A |
<0.01%
+1mV |
<0.3%
+1mV |
<3mV |
240x200x200 |
6 |
| PS1520 |
20A |
280x200x200 |
8 |
| PS1530 |
30A |
10 |
| PS3002 |
0-30V |
2A |
<0.01%
+0.5mV |
<0.3%
+0.5mV |
<1mV |
240x190x200 |
3.5 |
| PS3003 |
3A |
3.8 |
| PS3005 |
5A |
240x200x200 |
5.6 |
| PS3010 |
10A |
<0.01%
+1mV |
<0.3%
+1mV |
<3mV |
280x200x200 |
8 |
| PS3020 |
20A |
300x220x200 |
12 |
| PS3030 |
30A |
16 |
?? |
| YH1700 SERIES ADJUSTABLE CONSTANT VOLTAGE CONSTANT CURRENT POWER SUPPLY |
|
| Model |
Output?? |
Source Regulation |
Load Regulation |
Ripple(rms) |
Size(mm) |
Weight(kg) |
Voltage |
Current |
| YH1715 |
0-15V |
0-3A |
CV:<0.01%+0.5mV
CC:<0.5%+1ma |
CV:<0.01%+0.5mV
CC:<0.5%+1mV |
CV:<1mV
CC:<5mv |
220x190x200 |
3.1 |
| YH1715A |
0-5A |
240x190x200 |
3.9 |
| YH1715B |
0-10A
0-20A |
CV:<0.01%+1mV
CC:<0.5%+2mA |
CV:<0.3%+1mV
CC:<0.5%+10mV |
CV:<3mV
CC:<10mV |
240x200x200 |
6.1 |
| YH1715C |
280x200x200 |
8.1 |
| YH1730 |
0-30V |
0-3A |
CV:<0.01%+0.5mV
CC:<0.5%+1mA |
CV:<0.3%+0.5mV
CC:<0.5%+5mV |
CV:<1mV
CC:<5mV |
240x190x200 |
3.9 |
| YH1730A |
0-5A |
240x200x200 |
5.7 |
| YH1730B |
0-10A
0-20A |
CV:<0.01%+1mV
CC:<0.5%+2mA |
CV:<0.3%+1mV
CC:<0.5%+10mV |
CV:<3mV
CC:<10mV |
280x200x200 |
8.1 |
| YH1730C |
300x220x200 |
12.1 |
|
|
